- U-Value: 0.25 - 0.33 | R-Value: 4 | SGHC: 0.17 - 0.42
- Construction Depth: 2 3/4"
- Design Pressure: ±2400 Pa (±50.13 psf)
- Air Infiltration: <0.05 L/s/m2 (<0.01 cfm/ft2)
- Water Penetration Resistance: 580 Pa (12.11 psf)
- STC: up to STC42
- Min Size One Unit: 14" x 14"
- Max Size One Unit: 106" x 106"
- Max Glass Thickness: 1 39/64" - 41mm
- Installation Types: Through Frame, Straps
- Certifications: NFRC
